Aman Pipes and Tubes, a leading manufacturer and supplier based in Hyderabad, India, offers premium-grade Titanium Boiler Tubing designed for maximum performance in high-temperature and corrosive boiler environments. Our titanium boiler tubes are manufactured using superior quality titanium grades like Grade 2 and Grade 5, conforming to international standards such as ASTM B338 and B861. These tubes exhibit exceptional corrosion resistance, high thermal conductivity, and excellent durability. Widely used in heat exchangers, condensers, and power generation systems, Aman Pipes and Tubes provides long-lasting, lightweight, and energy-efficient titanium tubing solutions for critical boiler and thermal applications.
Titanium Boiler Tubing is typically made from Grade 2 (commercially pure titanium) and Grade 5 (Ti-6Al-4V). Grade 2 contains ≥99.2% titanium and offers excellent corrosion resistance with a tensile strength of ~350 MPa. Grade 5 includes 6% aluminum and 4% vanadium, delivering higher strength—up to 900 MPa. These tubes are lightweight, with low thermal expansion and high thermal conductivity, making them ideal for heat transfer systems. They maintain integrity under high temperatures and resist chemical attack from acids, chlorides, and seawater, ensuring reliable and long-term performance in industrial boiler applications.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance | Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or beveled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing | A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Boiler Tubing from Aman Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Aman Pipes and Tubes, a leading supplier of Titanium Boiler Tubing in Hyderabad, India, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Aman Pipes and Tubes, we provide custom sizes of Titanium Boiler Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@amanpipesandtubes.co.in.
Titanium Boiler Tubing from Aman Pipes and Tubes is widely used in power plants, chemical processing units, desalination facilities, and offshore platforms, where resistance to heat, corrosion, and pressure is critical. These tubes are ideal for steam condensers, feedwater heaters, heat exchangers, and evaporators operating in aggressive environments. Their superior corrosion resistance to seawater and industrial chemicals makes them ideal for marine boilers and nuclear reactors. Lightweight and efficient, titanium boiler tubing enhances heat transfer efficiency, reduces maintenance, and extends equipment lifespan, making it the preferred choice for high-performance thermal systems.
