Home > Stainless Steel > Stainless Steel 316/316L Heat Exchanger Tubing
Aman Pipes and Tubes, a well-known manufacturer and supplier located in Hyderabad, India, specializes in top-quality Stainless Steel 316/316L Heat Exchanger Tubing. This tubing is crafted for durability, efficiency, and outstanding resistance to corrosion. The austenitic stainless steels are perfect for heat transfer applications in harsh environments, including those with chlorides and other corrosive substances. SS 316 boasts high strength and excellent pitting resistance, while SS 316L, with its lower carbon content, enhances weldability and minimizes the risk of intergranular corrosion. Manufactured to meet international standards, Aman’s heat exchanger tubes promise high thermal conductivity, precise dimensions, and reliable performance in demanding industrial settings.
Stainless Steel 316/316L Heat Exchanger Tubing consists of Chromium (16–18%), Nickel (10–14%), and Molybdenum (2–3%), with carbon content capped at ≤0.08% for 316 and ≤0.03% for 316L. These elements significantly boost corrosion resistance, particularly against chlorides and acidic conditions. The tubing showcases a tensile strength of around 515 MPa, yield strength of about 205 MPa, and an elongation of roughly 40%. Its robust mechanical properties and seamless or welded design enable it to function effectively under high pressure and temperature, ensuring excellent thermal performance and long-lasting durability in corrosive heat transfer systems.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316 | SS 316L |
| C | 0.08 max | 0.035 max |
| Mn | 2.0 max | 2.0 max |
| Si | 1.0 max | 1.0 max |
| P | 0.045 max | 0.045 max |
| S | 0.030 max | 0.030 max |
| Cr | 16.00 – 18.00 | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 | 2.00 – 3.00 |
| Ni | 11.00 – 14.00 | 10.00 – 14.00 |
| Fe | 67.845 min | 68.89 min |
| Element | SS 316 | SS 316L |
| Density | 8.0 g/cm3 | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) | 1399 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 | Psi – 30000 , MPa – 205 |
| Elongation | 35 % | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316/316L Heat Exchanger Tubing from Aman Pipes and Tubes ensures access to high-quality materials tailored for durability and performance. With a commitment to excellence, Brydon offers precise dimensions and superior corrosion resistance, making their tubing ideal for challenging environments. The company’s expertise in manufacturing guarantees reliability and compliance with industry standards. Additionally, Brydon’s dedicated customer service provides personalized support, ensuring clients find the right solutions for their specific needs. Trust Aman Pipes and Tubes for unparalleled quality and performance in stainless steel heat exchanger tubing.
Aman Pipes and Tubes, one of the largest suppliers of Stainless Steel 316/316L Heat Exchanger Tubing in Hyderabad, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316/316L Heat Exchanger Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316/316L Heat Exchanger Tubing finds extensive use in chemical processing, power generation, petrochemicals, marine applications, and the food and beverage sector. It’s perfect for heat exchangers, condensers, boilers, evaporators, and cooling systems that deal with corrosive or high-temperature fluids. SS 316 is resistant to pitting and crevice corrosion, making it suitable for saltwater and acidic environments, while SS 316L is the go-to choice for welded structures where carbide precipitation needs to be avoided. These tubes deliver high strength, easy cleanability, and exceptional corrosion resistance, ensuring efficient operation in challenging conditions.
