Aman Pipes and Tubes, located in Hyderabad, India, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Monel Coil Tubing. This tubing is known for its outstanding resistance to both corrosion and mechanical stress. With a strong focus on quality and precision, the company produces coil tubing crafted from high-performance Monel alloys, designed for critical applications in the marine, chemical, and oil & gas sectors. Aman Pipes and Tubes stands out for its cutting-edge manufacturing techniques, prompt deliveries, and a customer-centric approach, making it the go-to choice for clients in need of durable and dependable tubing solutions for challenging environments.
Monel Coil Tubing is mainly made up of nickel (at least 63%) and copper (28–34%), along with small amounts of iron, manganese, carbon, and silicon. This alloy is renowned for its impressive corrosion resistance, particularly in marine and chemical settings. The tubing boasts high mechanical strength, with tensile strength between 550–620 MPa, yield strength ranging from 240–345 MPa, and elongation reaching up to 35%. Monel’s exceptional thermal and mechanical stability across a wide temperature range makes it ideal for applications that require outstanding durability and resistance to stress.
| End | Plain End, Beveled End, Treaded |
|---|---|
| Monel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Monel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Monel tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Specialize in | Monel Capillary Tube & Other Odd Size Monel Heat Exchanger & Condenser Tubes |
| Monel Tube Standards | ASTM B163, ASTM B730 /ASME SB163, ASME SB730 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Monel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Monel Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Marking | All Monel Alloy tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Monel Alloy Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Monel Alloy tube Length | Single Random, Double Random, Standard & Cut length |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Alloy K500 | 0.25 max | 1.50 max | 0.50 max | 0.010max | 27.00 – 33.00max | 0.5 – 2 | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44g\cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Coil Tubing from Aman Pipes and Tubes ensures exceptional corrosion resistance, high strength, reliable performance, and superior durability for optimal solutions in various industrial applications.
Aman Pipes and Tubes, one of the largest suppliers of Monel Coil Tubing in Hyderabad, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
Yes, we offer custom sizes for Monel Coil Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Monel Coil Tubing finds extensive use in oil and gas wells, chemical processing facilities, and marine systems, thanks to its remarkable resistance to seawater, acids, and alkalis. It’s often utilized in downhole and hydraulic control lines, chemical injection systems, and instrumentation tubing on offshore platforms. Its formability and corrosion resistance also make it a great fit for heat exchangers, evaporators, and cooling systems. In the aerospace sector, it’s employed in fuel lines and hydraulic systems. The coiled design allows for long, continuous lengths, ensuring seamless installation and minimizing leak points and maintenance in high-pressure, corrosive environments.
