Aman Pipes and Tubes, based in Hyderabad, India, has earned a solid reputation as a reliable manufacturer and supplier of high-quality Monel Boiler Tubing. Known for its exceptional quality and durability, the company offers both seamless and welded boiler tubing solutions that adhere to strict industry standards. Monel Boiler Tubing is specifically engineered to provide outstanding corrosion resistance and strength in challenging boiler environments, especially where seawater and acidic conditions are common. With a commitment to precision manufacturing and thorough quality checks, Aman Pipes and Tubes delivers dependable tubing products for power plants, marine boilers, and the chemical industry, ensuring excellence and timely delivery for clients both in India and abroad.
Monel Boiler Tubing is primarily made up of 63–70% Nickel and 28–34% Copper, along with trace amounts of Iron, Manganese, Carbon, and Silicon. This nickel-copper alloy is known for its remarkable resistance to corrosion, particularly in seawater and acidic settings. In terms of mechanical properties, Monel Boiler Tubing boasts a tensile strength ranging from 480 to 620 MPa, yield strength between 170 and 275 MPa, and an elongation of 35–45%. It also exhibits excellent toughness, ductility, and thermal stability at high temperatures, making it an ideal choice for boiler applications that demand both mechanical strength and resistance to corrosive flue gases and condensates.
| Boiler Tube Standard | ASTM B163, B730 / ASME SB163, SA730 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Monel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Monel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | ||
| Outside Diameter | Outside Diameter | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | inch | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Boiler Tubing from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our tubing is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Aman Pipes and Tubes, one of the largest suppliers of Monel Boiler Tubing in Hyderabad, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Our extensive inventory and commitment to exceptional service make us the go-to choice for Monel products in the region.
Yes, we offer custom sizes for Monel Boiler Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Monel Boiler Tubing finds extensive use in boiler systems where corrosion resistance and mechanical integrity are paramount. It’s particularly well-suited for marine and industrial boilers that face exposure to seawater and acidic condensates, ensuring long-lasting performance even in tough operating conditions. This tubing is commonly utilized in power generation plants, chemical processing boilers, and heat exchangers, where resistance to saltwater corrosion and high temperatures is crucial. Its durability and ability to handle thermal cycling make it a great fit for steam boilers, superheaters, and other demanding applications.
