Inconel welded pipes Manufacturer, Supplier and Exporter in Hyderabad, India

Hyderabad-based Aman Pipes and Tubes is a reliable manufacturer and supplier of high-grade Inconel welded pipes. Renowned for their exacting engineering and superior quality work, Aman Pipes and Tubes provides strong and reliable Inconel welded pipes customized to cater to varied industry requirements. Focused on maintaining highest quality standards and delivery schedules, they cater to an extensive clientele base across different industries, providing flawless performance under harsh conditions. Their state-of-the-art manufacturing operations and rigorous quality control ensure pipes that meet high standards in corrosion resistance and mechanical strength, such that Aman Pipes and Tubes are an industry leader’s favorite.

Nickel Alloy Welded Piping In India, ASTM B705 Inconel Welded Pipe In United kingdom, Inconel Alloy Welded Pipe Hyderabad, Inconel® Alloy Welded Pipe Supplier In Hyderabad , Alloy Welded Piping India, Nickel Alloy Pipe Price Per Kg In Hyderabad, Inconel® Alloy Welded Pipe India, Inconel Welded Pipe Stockist In Hyderabad, India.

Inconel welded pipes consist mainly of nickel, chromium, and iron, supplemented in different proportions by molybdenum, cobalt, and other elements depending on the particular Inconel grade. The alloy has outstanding resistance to oxidation and corrosion, particularly at high temperatures. In mechanical terms, Inconel welded pipes possess high tensile strength, superior toughness, and good ductility. They do not lose their structural characteristics when subjected to thermal cycling and severe pressures, which makes them ideal for applications where performance and durability are crucial.

Inconel welded pipes Specification

Welded Pipe Standard	ASTM B705 ASME SB705
Welded Pipe Dimension	ANSI/ASME B36.19M, ANSI/ASME B36.10M
Welded Pipe Sizes	1 / 2″ NB – 24″ NB
Welded Pipe Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Steel Welded Pipe Manufacturing Process	Welded / ERW / Fabricated / CDW / 100% X Ray Welded
Welded Pipe Shapes	Round, Rectangle, Square etc.
Welded Pipe Schedule	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Welded Pipe Ends	Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Pipes, Finish as per customer Requirements
Value Added Services	Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing

Inconel Welded Pipe Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Inconel® Alloy Welded Pipe India, Alloy Welded Pipe United kingdom, Nickel Alloy Welded Pipe In Hyderabad, Inconel Welded Pipe Exporter In Hyderabad , Inconel Welded Pipe Stockist In India, Inconel Welded Pipe Supplier In Hyderabad, Inconel Welded Pipe Supplier In India, ASTM B705 Alloy Welded Pipe India, Inconel Welded Pipe Stockist In Hyderabad, India.

Why Choose Inconel welded pipes from Aman Pipes and Tubes?

When you choose Inconel welded pipes from Aman Pipes and Tubes, you can count on exceptional quality and long-lasting durability. These tubes offer excellent corrosion resistance and high strength, making them perfect for various industrial applications. Our commitment to outstanding service and reliable delivery guarantees customer satisfaction with every order. With extensive expertise in stainless steel products, we provide premium solutions tailored to meet your unique needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Inconel welded pipes Supplier in Hyderabad, India

Aman Pipes and Tubes, a top supplier of Inconel welded pipes in Hyderabad, India, offers a comprehensive range of high-quality pipes and tubes for various industrial applications. With an extensive inventory and a commitment to exceptional customer service, they have become the go-to source for stainless steel products in the area.

Nickel Alloy Welded Piping In India, ASTM B705 Inconel Welded Pipe In United kingdom, Inconel Alloy Welded Pipe Hyderabad, Inconel® Alloy Welded Pipe Supplier In Hyderabad ,
Alloy Welded Piping India, Nickel Alloy Pipe Price Per Kg In Hyderabad, Inconel® Alloy Welded Pipe India, Inconel Welded Pipe Stockist In Hyderabad, India.

Types of Inconel welded pipes

Are Custom Sizes Available for Inconel welded pipes?

At Aman Pipes and Tubes, we specialize in providing custom-sized Inconel welded pipes designed to meet your specific requirements. Our expert team is committed to delivering personalized solutions for all your piping and tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.

Inconel® Alloy Welded Pipe India, Alloy Welded Pipe United kingdom, Nickel Alloy Welded Pipe In Hyderabad, Inconel Welded Pipe Exporter In Hyderabad , Inconel Welded Pipe Stockist In India, Inconel Welded Pipe Supplier In Hyderabad, Inconel Welded Pipe Supplier In India, ASTM B705 Alloy Welded Pipe India, Inconel Welded Pipe Stockist In Hyderabad, India.

Inconel welded pipes find extensive application in industries like aerospace, chemical processing, power generation, and petrochemical industries. Their high resistance against heat, corrosion, and oxidation due to their face-centered cubic crystal structure makes them apt for high-temperature and aggressive environment applications. Pipes made of these are utilized in heat exchangers, gas turbines, nuclear reactors, and offshore oil drilling rigs. Further, they are preferred in the production of chemical reactors, pressure vessels, and exhaust systems where safety and durability are key. Aman Pipes and Tubes makes sure that their Inconel welded pipes are highly resistant to industry standards and meet demands from domestic as well as global markets.
