Home > Duplex Steel > Duplex Steel Tubing 2205
Aman Pipes and Tubes is a prominent player in the piping industry, known for its expertise in manufacturing and supplying Duplex Steel Tubing 2205 right from Hyderabad, India. The company has built a solid reputation for delivering high-quality products that excel in performance, tailored to meet a variety of industrial needs. With a strong emphasis on innovation and precision, Aman Pipes and Tubes serves sectors such as oil and gas, petrochemicals, and marine engineering. Their unwavering commitment to excellence ensures that clients receive top-tier solutions customized to their unique requirements, making them a reliable partner in the marketplace.
Duplex Steel Tubing 2205 is a high-performance alloy that consists of 22% chromium, 5% nickel, and 3% molybdenum, along with balanced nitrogen additions to boost its strength and resistance to corrosion. This alloy features a unique blend of austenitic and ferritic microstructures, which provide outstanding mechanical properties, including a minimum tensile strength of 620 MPa and a yield strength of at least 450 MPa. Duplex 2205 is particularly resistant to stress corrosion cracking, pitting, and crevice corrosion, making it perfect for tough environments. Its remarkable weldability and toughness further enhance its suitability for various industrial applications.
| Tube Specifications |
|
|---|---|
| Tube Standard | DIN, JIS, ASTM, EN, GB, AISI, ASME Tube Supplier |
| Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Length | Single Random, Double Random, Standard & Cut length |
| Type | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Tube |
| Tube Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Tube Thickness | 0.3mm – 50 mm |
| Seamless Tube Outer Diameter | 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB |
| EFW Tube size | 5.0 mm – 1219.2 mm |
| Welded Tube size | 5.0 mm – 1219.2 mm |
| wall thickness | 0.020″ –0.220″ (special wall thicknesses available) |
| End | Plain End, Beveled End, Treaded Tube. |
| Specialized in |
|
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Tube Marking | All Tubes are marked as follows: Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Boiler and Heatexchanger, Oil Tube, Fluid Tube, Gas Tube, |
| Form | Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Tubes, “U” Shape, Pan Cake Coils etc. |
| Material Test Certificates (MTC) |
|
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish,etc |
| Chemical Composition % | ||||
| Cr | Ni | Mo | C | N |
| 22.0-23.0 | 4.50-6.50 | 3.00-3.50 | .030 Max | 0.14-0.20 |
| Mn | Si | P | S | Fe |
| 2.00 Max | 1.00 Max | .030 Max | .020 Max | Balance |
PIPE STANDARD | WERKSTOFF NR. | UNS |
Duplex 2205 Tube | 1.4462 / 1.4462 | S31803 / S32205 |
| Duplex Stainless Steel | 2205 |
| Density | 7.805 |
| Melting Range,℃ | 1450 ℃ |
| Elongation % | 25 min. |
| Tensile Strength (Mpa) | 655 |
| Yield Strngth (Mpa) | 450 |
| Hardness (Brinell) | 293 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Duplex Steel Tubing 2205 from Aman Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Duplex steel solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Aman Pipes and Tubes, one of the largest suppliers of Duplex Steel Tubing 2205 in the Hyderabads, India. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Duplex steel products in the region, delivering reliable solutions to meet diverse project requirements.
Yes, we provide custom sizes for Duplex Steel Tubing 2205 to meet your specific requirements. At Aman Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@amanpipesandtubes.co.in.
Duplex Steel Tubing 2205 is extensively utilized in industries that demand exceptional corrosion resistance and high strength. You’ll find it in oil and gas processing systems, chemical processing plants, and marine settings where protection against chloride-induced corrosion is essential. This tubing is also employed in heat exchangers, pressure vessels, and desalination plants due to its impressive durability and thermal conductivity. Additionally, it plays a role in pulp and paper production, storage tanks, and structural components in harsh environments. Overall, Duplex 2205 tubing is a versatile and dependable choice for industries facing challenging operational conditions.
