Home > Copper Nickel > Copper Nickel Boiler Tubing
Aman Pipes and Tubes, a prominent manufacturer and supplier located in Hyderabad, India, focuses on delivering high-quality Copper Nickel Boiler Tubing designed for demanding industrial applications. Renowned for their resistance to corrosion, excellent thermal conductivity, and impressive durability, Copper Nickel Boiler Tubes are perfect for marine and power generation settings. The company produces tubing that meets international standards, providing precision-engineered solutions tailored to the unique needs of their clients. With a strong foundation in technical expertise and a dedication to quality, Aman Pipes and Tubes supports industries like shipbuilding, desalination, and thermal power with dependable and long-lasting tubing products.
Copper Nickel Boiler Tubing is generally crafted from alloys like Cu-Ni 90/10 (90% Copper, 10% Nickel) or Cu-Ni 70/30 (70% Copper, 30% Nickel), with small amounts of Iron and Manganese added to boost strength and corrosion resistance. These alloys excel in resisting biofouling and seawater corrosion. The tubing boasts a tensile strength ranging from 275 to 500 MPa, a yield strength of about 120 to 190 MPa, and an elongation of 30 to 45%. Copper Nickel tubes maintain their mechanical integrity even under high pressure and temperature, providing outstanding thermal conductivity and long-lasting performance in boiler and heat exchanger applications.
| Boiler Tube Standard | ASTM B552 / ASME SB552 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Cupro Nickel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Cupro Nickel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Properties | Imperial | Metric |
|---|---|---|
| Yield strength (depending on temper) | 40000-76000 psi | 276-524 MPa |
| Shear modulus | 6380 ksi | 44.0 GPa |
| Tensile strength | 38000-77000 psi | 262-531 MPa |
| Elongation at break (in 50.8 mm) | 46% | 46% |
| Poisson’s ratio | 0.34 | 0.34 |
| Elastic modulus | 17000 ksi | 117 GPa |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Designation | Chemical Composition % | ||||||||
| Cu | Sn | Al | As | Ni | Fe | Mn | Pb max. | Zn | |
| C70400 | Rem | – | – | – | 4.8-6.2 | 1.3-1.7 | 0.3-0.8 | 0.05 | 1.0max |
| Property |
Metric Units |
Imperial Units |
|---|---|---|
|
Melting Point (Liquidus) |
11,500°C |
21,000°F |
|
Melting Point (Solidus) |
11,000°C |
20,100°F |
|
Density |
8.94 gm/cm³ @ 20°C |
0.323 lb/in³ @ 68°F |
|
Specific Gravity |
8.94 |
8.94 |
|
Coefficient of Thermal Expansion |
17.1 x 10 -6 / °C (20-300°C) |
9.5 x 10 -5 / °F (68-392°F) |
|
Themal Conductivity |
40 W/m. °K @ 20°C |
23 BTU/ft³/ft/hr/°F @ 68°F |
|
Thermal Capacity (Specific Heat) |
380 J/kg. °K @ 20°C |
0.09 BTU/lb/°F @ 68°F |
|
Electrical Conductivity (Annealed) |
5.26 microhm?¹.cm?¹ @ 20°C |
9.1% IACS |
|
Electrical Resistivity (Annealed) |
0.190 microhm.cm @ 20°C |
130 ohms (circ mil/ft) @ 68°F |
|
Modulus of Elasticity (tension) |
140 GPa @ 20°C |
20 x 10 6 psi @ 68°F |
|
Modulus of Rigidity (torsion) |
52 GPa @ 20°C |
7.5 x 10 6 psi @ 68°F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Copper Nickel Boiler Tubing from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Choose Copper Nickel Boiler Tubing from Aman Pipes and Tubes for its superior seawater corrosion resistance, biofouling protection, and excellent thermal conductivity, making it ideal for marine, industrial, and coastal applications requiring long-lasting performance and reliability.
Yes, we offer custom sizes for Copper Nickel Boiler Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Copper Nickel Boiler Tubing finds extensive use in marine settings, including shipbuilding, offshore platforms, and seawater cooling systems, thanks to its corrosion and biofouling resistance. In power plants, it’s ideal for boilers, condensers, and heat exchangers, where thermal conductivity and scale resistance are essential. The desalination sector utilizes it in evaporators and brine heaters. Additionally, it’s well-suited for HVAC systems, petrochemical processing, and industrial heating applications. Copper Nickel’s ability to perform reliably under high pressure and temperature makes it a top choice for these demanding environments.
