Home > Copper Nickel > Copper Nickel 90/10 Tubing
Aman Pipes and Tubes, based in Hyderabad, India, has earned a solid reputation as a reliable manufacturer and supplier of high-quality Copper Nickel 90/10 Tubing, which is essential for various marine and industrial applications. This tubing is celebrated for its outstanding resistance to seawater corrosion and biofouling, making it a popular choice for heat exchangers, condensers, and fluid handling systems. Aman Pipes and Tubes ensures that their products meet rigorous international standards, guaranteeing durability, strength, and excellent thermal conductivity. With a strong focus on quality, timely delivery, and technical expertise, the company confidently serves industries like shipbuilding, desalination, power generation, and offshore engineering.
Copper Nickel 90/10 Tubing consists of 90% Copper and 10% Nickel, with minor additions of Iron (1.0–1.8%) and Manganese (up to 1.0%) to boost its resistance to corrosion and erosion. This alloy excels in saline environments, providing impressive performance. The tubing typically boasts a tensile strength ranging from 300–500 MPa, a yield strength of 100–150 MPa, and an elongation of about 30–40%. It remains mechanically stable under moderate pressure and temperature conditions and is recognized for its good weldability, thermal conductivity, and resistance to pitting and stress corrosion cracking, making it ideal for a variety of applications.
Specification : ASTM B466, B467, B111 / ASME SB466, SB467, SB111
Standard : ASTM, ASME and API
Size : 1/2″ TO 6′ IN OD & NB IN Various SWG & SCH
Outer Diameter : 4.00 to 22.00 mm
Wall Thickness : Between 0.15mm and 1.50 mm
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
| Product Property | US Customary |
|---|---|
| Coefficient of Thermal Expansion | 9.5 10−6Per °F (68-572 F) |
| Density | 0.323 lb/in3 at 68 F |
| Electrical Conductivity | 9 %IACS @ 68 F |
| Electrical Resistivity | 115.0 ohms-cmil/ft @ 68 F |
| Melting Point – Liquidus | 2100 F |
| Melting Point – Solidus | 2010 F |
| Modulas of Elasticity in Tension | 18000 ksi |
| Modulus of Rigidity | 6800 ksi |
| Specific Gravity | 8.94 |
| Specific Heat Capacity | 0.09 Btu/lb/°F at 68 F |
| Thermal Conductivity | 26.0 BTU in/hr.ft2.°F @ 68 F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Copper Nickel 90/10 Tubing from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Choose Copper Nickel 90/10 Tubing from Aman Pipes and Tubes for its superior seawater corrosion resistance, biofouling protection, and excellent thermal conductivity, making it ideal for marine, industrial, and coastal applications requiring long-lasting performance and reliability.
| Outer Diameter) Sizes | Wall Thk. |
|---|---|
| 3/16″, 1″, 1 5/8″, 3/8″, 16″, 7/8″, 5/16″, 1 1/2″, 7/16″, 1/4″, 2″, 5/8″, 1/2″, 3/4″, 1/8″, 1 1/4″, 2 1/4″ | 0.035 |
| 1/8″ , 3/16″ | 0.016 |
| 1/16″, 1/8″, 3/16″ | 0.010 |
| 1/16″, 1/8″, 1/4″ 3/16″, 3/8″, 5/16″ | 0.020 |
| 1/8″ | 0.012 |
| 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/2″, 1 1/4″, 1 5/8″, 1 7/8″, 2″, 2 1/2″, 3″ | 0.083 |
| 1″ | .134 |
| 1/4″, 5/16″, 3/8″, 1/2″, 16″, 5/8″, 3/4″, 7/8″, 1″, 1 1/2″, 1 1/4″, 1 5/8″, 1 3/4″, 2″, 2 1/2″, 3″ | 0.065 |
| 3 1/2″ | .375 |
| 1/8″, 1/4″ 3/16″, 3/8″, 5/16″, 1/2″, 3/4″, 1″, 1 1/2″, 2″ | 0.028 |
| 3/4″, 1 1/4″, 1″, 1 1/2″, 2″, 3″, 3 1/4″ | .125 |
| 1/2″, 5/8″, 1 1/4″, 1″, 1 1/2″, 2″ | 0.095 |
| 1/2″, 3/4″, 1 1/4″, 1″, 1 1/2″, 2″ | .109 |
| 3″ | .250 |
| 1/2″, 5/8″, 3/4″, 7/8″, 1 1/4″, 1″, 1 1/2″, 2″, 2 1/4″, 2 1/2″, 3″ | .120 |
| 1/4″, 3/16″, 3/8″, 5/16″, 1/2″, 16″, 5/8″, 3/4″, 7/8″, 1″, 1 1/8″, 1 1/2″, 1 1/4″, 1 5/8″, 2″, 2 1/4″ |
Yes, we offer custom sizes for Copper Nickel 90/10 Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Copper Nickel 90/10 Tubing finds extensive use in marine settings, including seawater cooling, bilge and ballast systems, and desalination units, thanks to its remarkable corrosion and biofouling resistance. It’s also utilized in shipbuilding, offshore oil rigs, and naval vessels for firewater and hydraulic systems. In the realms of power generation and chemical processing, it plays a vital role in heat exchangers, evaporators, and condensers. Furthermore, this tubing is commonly found in HVAC systems, brine heaters, and underwater piping systems, providing a long service life and dependable performance in challenging environments.
