Carbon Steel JISG3462 Pipes Manufacturer, Supplier and Exporter in Hyderabad, India

Located in Hyderabad, India, Aman Pipes and Tubes is a reputable producer and supplier of Carbon Steel JIS G3462 Pipes, providing excellent piping solutions for applications requiring high pressure and temperature. These pipes are appropriate for boiler and heat exchanger systems since they are made in accordance with the Japanese Industrial Standard (JIS G3462). Long-term performance and dependability are guaranteed by Aman’s JIS G3462 pipes, which are renowned for their exceptional mechanical strength and heat resistance. Aman serves both domestic and foreign markets by providing precision manufacturing, stringent quality control, and prompt delivery to sectors like thermal processing, petrochemicals, and power generation.

JIS G3462 Carbon Steel Pipes Supplier in Hyderabad, G3462 Pipes Exporter in India, Schedule 10 Carbon Steel JIS G3462 Pipes Manufacturer in Hyderabad , JIS G3462 Pipe Price List in Hyderabad, JIS G3462 Distributor in Hyderabad, JIS G3462 CS Pipes in India, JIS G3462 Pipe Supplier in Hyderabad , Carbon Steel JIS G3462 Pipes Distributor in India, JIS G3462 Sizes in mm

The main constituents of carbon steel JIS G3462 pipes are carbon, silicon, phosphorus, manganese, and sulphur in regulated proportions. These seamless steel pipes are made to withstand high temperatures, particularly in heat exchangers and boilers. They usually have an elongation of 25–30%, a yield strength of about 285 MPa, and a tensile strength of 440–610 MPa. These pipes are very reliable for pressurised applications involving hot steam or fluids because they have good weldability, thermal stability, and resistance to oxidation and creep at high temperatures.

Carbon Steel JISG3462 Pipes Specification

Standards	JIS G3462 Carbon Steel Pipe
JIS G3462 Carbon Steel Seamless Pipe Size	4 to 219mm W. T.: 0.5 to 20mm
JIS G3462 Carbon Steel Welded Pipe Size	5.0 mm – 1219.2 mm
JIS G3462 Carbon Steel EFW Pipe size	5.0 mm – 1219.2 mm
JIS G3462 Carbon Steel Tube Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
JIS G3462 Carbon Steel Pipe Schedule	SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
JIS G3462 Carbon Steel Seamless Tube Size	3.35 mm OD To 101.6 mm OD
JIS G3462 Carbon Steel Welded Tube Size	6.35 mm OD To 152 mm OD
Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
JIS G3462 Carbon Steel Tube wall thickness	0.020″ –0.220″, (special wall thicknesses available)
Length	Single Random, Double Random, Standard & Cut length Pipe & Tube
Finish	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
Form	Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc
Type	Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc
End	Plain End, Beveled End, Treaded Pipe & Tube
Marking	All JIS G3462 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Application	Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube
Value Added Service	Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc.
Test Certificate	Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection

Carbon Steel JISG3462 Pipes Chemical Composition

Grade	Chemical Composition Limits (%)
Grade	C	Si	Mn	P	S	Cr	Mo
JIS G3462 STBA12	0.10-0.20	0.10-0.50	0.30-0.80	≤ 0.035	≤ 0.035	–	0.45-0.65
JIS G3462 STBA13	0.15-0.25	0.10-0.50	0.30-0.80	≤ 0.035	≤ 0.035	–	0.45-0.65
JIS G3462 STBA20	0.10-0.20	0.10-0.50	0.30-0.60	≤ 0.035	≤ 0.035	0.050-0.080	0.45-0.65
JIS G3462 STBA22	≤ 0.15	≤ 0.50	0.30-0.60	≤ 0.035	≤ 0.035	0.80-1.25	0.45-0.65
JIS G3462 STBA23	≤ 0.15	0.50-1.00	0.30-0.60	≤ 0.030	≤ 0.030	1.00-1.50	0.45-0.65
JIS G3462 STBA24	≤ 0.15	≤ 0.50	0.30-0.60	≤ 0.030	≤ 0.030	1.90-2.60	0.87-1.13
JIS G3462 STBA25	≤ 0.15	≤ 0.50	0.30-0.60	≤ 0.030	≤ 0.030	4.00-6.00	0.45-0.65
JIS G3462 STBA26	≤ 0.15	0.25-1.00	0.30-0.60	≤ 0.030	≤ 0.030	8.00-10.00	0.90-1.10

Carbon Steel JISG3462 Pipes Mechanical Properties

Grade	Tensile Property (N/mm2) ( ≥ )	Yield Point or Yield Strength (N/mm2) ( ≥ )	Elongation (%)
			OD ≥ 20 mm	10 mm ≤ OD ＜20 mm	OD ＜10 mm
			NO. 11 Sample; NO. 12 Sample	NO. 11 Sample	NO. 11 Sample
			Longitudinal	Transverse	Transverse
JIS G3462 STBA12	382	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA13	412	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA20	412	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA22	412	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA23	412	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA24	412	206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA25	412	≥ 206	≥ 30	≥ 25	≥ 22
JIS G3462 STBA26	412	206	≥ 30	≥ 25	≥ 22

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Carbon Steel JIS G3462 Pipes Supplier in Hyderabad, CS JIS G3462 Pipes Exporter in India, Schedule 40 CS JIS G3462 Pipe Sizes in mm, JIS G3462 Manufacturer in Hyderabad , JIS G3462 CS Pipes Price List in Hyderabad, JIS G3462 Carbon Steel Pipes Distributor in Hyderabad,JIS G3462 CS Pipes in India,CS JIS G3462 Pipes Supplier in Hyderabad , JIS G3462 High Pressure Steel Pipe Distributor in India

Why Choose Carbon Steel JISG3462 Pipes from Aman Pipes and Tubes?

Choosing Carbon Steel JISG3462 Pipes from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Carbon Steel JISG3462 Pipes Supplier in Hyderabad, India

Aman Pipes and Tubes is one of the largest Carbon Steel JISG3462 Pipes suppliers in Hyderabad, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

CS JIS G3462 Pipes Exporter in India, Schedule 10 Carbon Steel JIS G3462 Pipes Price List in Hyderabad, JIS G3462 Pipes Supplier in India, Carbon Steel JIS G3462 Pipes Exporter in Hyderabad , Schedule 40 CS JIS G3462 Pipe Exporter in Hyderabad, G3462 Carbon Steel Pipes Size Chart, JIS G3462 Pipe Price in India, Schedule 40 CS JIS G3462 Pipe Weight Chart, JIS G3462 Carbon Steel Pipes Thickness, JIS G3462 Pipe Supplier in Hyderabad, Carbon Steel JIS G3462 Pipes Stockist in India

Types of Carbon Steel JISG3462 Pipes

Are Custom Sizes Available for Carbon Steel JISG3462 Pipes?

Yes, we offer custom sizes for Carbon Steel JISG3462 Pipes to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.

JIS G3462 High Pressure Steel Pipe Exporter in India, JIS G3462 CS Pipes Price List in Hyderabad, Schedule 10 Carbon Steel JIS G3462 Pipes Supplier in India, JIS G3462 Carbon Steel Pipes Exporter in Hyderabad , G3462 Pipes Exporter in Hyderabad, JIS G3462 Pipe Size Chart, JIS G3462 Price in India, JIS G3462 High Pressure Steel Pipe Weight Chart, JIS G3462 CS Pipes Thickness, CS JIS G3462 Pipes Supplier in Hyderabad,JIS G3462 Pipe Stockist in India

Carbon Steel JISG3462 Pipes Uses

Boilers, superheaters, and heat exchangers in power plants and thermal stations are among the many applications for carbon steel JIS G3462 pipes in high-temperature and high-pressure settings. They are used in the petrochemical industry to move gases and fluids with high temperatures. Because they can tolerate pressure and heat without deforming, these pipes are also essential in refineries, industrial heaters, and chemical processing machinery. Their ability to withstand mechanical stress, corrosion, and thermal cycling makes them perfect for heavy-duty piping systems, pressure vessels, and mechanical tubing.
