Carbon Steel DIN 17175 Pipes Manufacturer, Supplier and Exporter in Hyderabad, India

Aman Pipes and Tubes, a reputable manufacturer and supplier located in Hyderabad, India, proudly offers top-notch Carbon Steel DIN 17175 Pipes. Renowned for their outstanding durability, precise engineering, and compliance with international standards, these pipes are specifically designed to handle the rigors of high-pressure and high-temperature applications. Utilizing advanced manufacturing techniques and thorough quality inspections, Aman Pipes and Tubes guarantees that every product performs at its best. Perfect for a variety of industries, their Carbon Steel DIN 17175 Pipes stand as a benchmark for reliability and efficiency in piping solutions.

17175 Carbon Steel Thin Wall Pipe Supplier in Hyderabad, DIN 17175 CS Pipe Exporter in India, 17175 Carbon Steel Pipe Sizes in mm, DIN 17175 CS Pipe Manufacturer in Hyderabad , Carbon Steel DIN 17175 Pipes Price List in Hyderabad, Large Diameter DIN 17175 Carbon Steel Pipe Distributor in Hyderabad, Carbon Steel DIN 17175 Pipes in India, Carbon Steel 17175 Pipes Supplier in Hyderabad , DIN 17175 CS Pipes Distributor in India

The Carbon Steel DIN 17175 Pipes are crafted from premium-grade steel, featuring a meticulously controlled blend of carbon, manganese, silicon, sulfur, and phosphorus. These pipes boast remarkable mechanical properties, including high tensile strength, yield strength, and impressive thermal stability. Built to thrive in extreme conditions, they are ideal for high-pressure and high-temperature applications. With heat treatment enhancing their durability and corrosion resistance, these pipes adhere to strict international standards, ensuring they deliver long-lasting and efficient performance in industrial settings.

Carbon Steel DIN 17175 Pipes Specification

Dimensions : ASTM, ASME and API
Standard : BS 3059
Outside Diameter : 5-90 mm
Wall Thickness : 0.5-15 mm
Length :in any length from 4 m to 12 m as per customer choice
Type :Seamless, Welded, ERW
End :Plain End, Beveled End, Treaded
Schedules :SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules

Carbon Steel DIN 17175 Pipes Chemical Composition

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35	0.15-0.30

Carbon Steel DIN 17175 Pipes Mechanical Properties

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASME SA213 DIN 17175 Pipe Exporter in India, Carbon Steel DIN 17175 Pipes Price List in Hyderabad, DIN 17175 CS Pipes Supplier in India, Carbon Steel DIN 17175 Pipes Exporter in Hyderabad , DIN 17175 Carbon Steel Pipes Exporter in Hyderabad, ASTM A213 Carbon Steel DIN 17175 Pipes Size Chart, Carbon Steel DIN 17175 Pipes Price in India, DIN 17175 Carbon Steel Pipe Weight Chart, Schedule 40 DIN 17175 Carbon Steel Pipe Thickness, DIN 17175 Pipes Supplier in Hyderabad, Carbon Steel DIN 17175 Pipes Stockist in India

Why Choose Carbon Steel DIN 17175 Pipes from Aman Pipes and Tubes?

Choosing Carbon Steel DIN 17175 Pipes from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Carbon Steel DIN 17175 Pipes Supplier in Hyderabad, India

Aman Pipes and Tubes is one of the largest Carbon Steel DIN 17175 Pipes suppliers in Hyderabad, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

Carbon Steel DIN 17175 Pipes Dimensions

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASTM A335 DIN 17175 Pipe Exporter in India, DIN 17175 Carbon Steel Pipe Price List in Hyderabad, DIN 17175 CS Pipe Supplier in India, Carbon Steel DIN 17175 Pipes Exporter in Hyderabad , Carbon Steel DIN 17175 Pipes Exporter in Hyderabad, DIN 17175 Pipes Size Chart, 17175 Carbon Steel Pipe Price in India, DIN 17175 Pipes CS Weight Chart, Carbon Steel DIN 17175 Pipes Thickness, CS DIN 17175 Pipes Supplier in Hyderabad, 17175 Carbon Steel Thin Wall Pipe Stockist in India

Types of Carbon Steel DIN 17175 Pipes

Are Custom Sizes Available for Carbon Steel DIN 17175 Pipes?

Yes, we offer custom sizes for Carbon Steel DIN 17175 Pipes to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.

Carbon Steel DIN 17175 Pipes Supplier in Hyderabad, 17175 Carbon Steel Thin Wall Pipe Exporter in India, CS DIN 17175 Pipes Manufacturer in Hyderabad , Carbon Steel DIN 17175 Pipes Price List in Hyderabad, DIN 17175 Pipes Carbon Steel Distributor in Hyderabad, 17175 CS Pipes in India, DIN 17175 Pipes Supplier in Hyderabad , Carbon Steel DIN 17175 Pipes Distributor in India, CS DIN 17175 Pipe Sizes in mm

Carbon Steel DIN 17175 Pipes find extensive use across various industries, including power generation, petrochemicals, oil and gas, and boiler manufacturing. Their capability to withstand high temperatures and pressures makes them crucial for applications like boiler tubes, heat exchangers, and superheater components. Additionally, these pipes are widely employed in chemical processing plants, refineries, and other high-stress environments. Their exceptional strength and reliability make them the go-to choice for demanding applications, ensuring seamless performance and a long service life in both onshore and offshore installations.
