Home > Carbon Steel > Carbon Steel API 5L Grade X56 Pipes
Aman Pipes and Tubes, based in Hyderabad, India, stands out as a top manufacturer and supplier of Carbon Steel API 5L Grade X56 Pipes. Known for their exceptional quality, durability, and adherence to international standards, these pipes are designed to meet the rigorous demands of various industrial applications. With cutting-edge manufacturing techniques and a commitment to innovation, Aman Pipes and Tubes provides products that guarantee efficiency and reliability. Whether it’s for oil and gas, water transportation, or structural uses, their Carbon Steel API 5L Grade X56 Pipes are a symbol of excellence and trust.
The Carbon Steel API 5L Grade X56 Pipes are crafted with a precisely balanced mix of carbon, manganese, phosphorus, sulfur, and silicon, ensuring top-notch performance. These pipes boast impressive mechanical properties, including high tensile strength, yield strength, and significant elongation, making them perfect for high-stress environments. They undergo heat treatment to boost their toughness and wear resistance, promising a long service life even in extreme conditions. Their design guarantees reliability in applications that demand high pressure and temperature resistance.
X56 Pipe Sizes: Nominal Pipe Size 1/2″ to 48 ” O.D.
Wall Thickness: Schedule 10 through 160, STD, XS, XXS.
API 5L X56 Seamless Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450)
DIMENSION: FROM 1/4” UP TO 24”
API 5L X56 Welded Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450) – X70 (L485) – X80 (L555)
DIMENSION: FROM 1/2” UP TO 60”
Weld Alternatives: ERW, HF, DSAW/SAWL, SMLS, HSAW
X56 Pipe Product Specification Level: API 5L X56 PSL 2, API 5L X56 PSL 1
Additional Services: Internal Coating
API 5L Grade B Hot Selling Grades: API 5L X42 Pipe, API 5L X46 Pipe, API 5L X52 Pipe, API 5L X56 Pipe, API 5L X60 Pipe, API 5L X65 Pipe, API 5L X70 Pipe
| Grade | Composition, % | |||||||
|---|---|---|---|---|---|---|---|---|
| C max | Mn max | P | S max | V max | Nb max | Ti max | ||
| min | max | |||||||
| B | 0.28 | 1.2 | – | 0.03 | 0.03 | c.d | c,d | d |
| X56 | 0.28 | 1.4 | – | 0.03 | 0.03 | d | d | d |
| Grade | Yield Strength Mpa | Tensile Strength Mpa | Elongation |
|---|---|---|---|
| B | 245 | 415 | c |
| X56 | 390 | 490 | c |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel API 5L Grade X56 Pipes from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
| ASTM API 5L | Specification for line pipe | |
|---|---|---|
| Material Grade | PSL1 | L390 or x56 |
| Material Grade | PSL2 | L390N or X56N L390Q or X56Q L390M or X56M |
| API 5L X56 | PSL2 |
|---|---|
| Minimum Yield Strength: | 56,000 psi |
| Maximum Yield Strength: | 79,000 psi |
| Minimum Tensile Strength: | 71,000 psi |
| Maximum Tensile Strength: | 110,000 psi |
| Notes: This is a standard line pipe grade specifiedin API (American Petroleum Institute) specification 5L. | |
Aman Pipes and Tubes is one of the largest Carbon Steel API 5L Grade X56 Pipes suppliers in Hyderabad, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel API 5L Grade X56 Pipes to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Carbon Steel API 5L Grade X56 Pipes find extensive use in industries like oil and gas, petrochemical, and water treatment. Their sturdy construction and excellent resistance to high pressures make them ideal for transporting crude oil, natural gas, and water over long distances. Additionally, they serve in structural applications such as building frameworks and industrial equipment. These pipes are particularly well-suited for both onshore and offshore pipelines, ensuring safe and efficient fluid transfer. Their versatility and performance make them a go-to choice for critical infrastructure and energy projects around the globe.
