Home > Carbon Steel > Carbon Steel API 5L Grade X46 Pipes
Aman Pipes and Tubes, located in Hyderabad, India, has earned a solid reputation as a reliable manufacturer and supplier of Carbon Steel API 5L Grade X46 Pipes. These pipes are specifically designed for the efficient transmission of oil, gas, and water, and are built to meet the rigorous demands of pipeline projects worldwide. Available in both PSL1 and PSL2 specifications, our API 5L X46 pipes boast impressive strength, excellent weldability, and strong corrosion resistance. With a focus on product reliability, technical accuracy, and prompt delivery, Aman Pipes and Tubes delivers robust piping solutions that align with industry standards and the critical needs of the energy sector.
Carbon Steel API 5L Grade X46 Pipes primarily consist of Carbon (up to 0.26%) and Manganese (up to 1.40%), along with carefully controlled levels of Phosphorus, Sulfur, and other alloying elements according to PSL specifications. These pipes provide a minimum yield strength of 317 MPa and a tensile strength that ranges from 434 to 758 MPa. Designed for moderate to high-pressure applications, X46 grade pipes excel in toughness and ductility. With their excellent weldability and structural integrity, API 5L X46 pipes are perfect for critical applications that demand superior mechanical performance and reliability.
| API 5L-PSL 1 Mechanical Properties | |||
|---|---|---|---|
| Grade | Yield Strength Mpa | Tensile Strength Mpa | Elongation |
| B | 245 | 415 | c |
| X46 | 320 | 435 | c |
| Grade | Composition, % | |||||||
|---|---|---|---|---|---|---|---|---|
| C max | Mn max | P | S max | V max | Nb max | Ti max | ||
| min | max | |||||||
| B | 0.28 | 1.2 | – | 0.03 | 0.03 | c.d | c,d | d |
| X46 | 0.28 | 1.4 | – | 0.03 | 0.03 | d | d | d |
X46 Pipe Sizes: Nominal Pipe Size 1/2″ to 48 ” O.D.
Wall Thickness: Schedule 10 through 160, STD, XS, XXS.
API 5L X46 Seamless Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450)
DIMENSION: FROM 1/4” UP TO 24”
API 5L X46 Welded Pipe: B (L245) – X42 (L290) – X52N (L360) – X60 (L415) – X65 (L450) – X70 (L485) – X80 (L555)
DIMENSION: FROM 1/2” UP TO 60”
Weld Alternatives: ERW, HF, DSAW/SAWL, SMLS, HSAW
X46 Pipe Product Specification Level: API 5L X46 PSL 2, API 5L X46 PSL 1
Additional Services: Internal Coating
API 5L Grade B Hot Selling Grades: API 5L X42 Pipe, API 5L X46 Pipe, API 5L X52 Pipe, API 5L X56 Pipe, API 5L X60 Pipe, API 5L X65 Pipe, API 5L X70 Pipe
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel API 5L Grade X46 Pipes from Aman Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Aman Pipes and Tubes is one of the largest Carbon Steel API 5L Grade X46 Pipes suppliers in Hyderabad, India, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel API 5L Grade X46 Pipes to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
Carbon Steel API 5L Grade X46 Pipes find extensive use in high-pressure oil and gas transportation pipelines, petrochemical processing, natural gas distribution systems, and offshore platforms. They are particularly suited for long-distance pipeline networks where strength, durability, and resistance to corrosive environments are crucial. Additionally, these pipes are utilized in power generation, refinery operations, and structural applications within heavy engineering. Whether installed above ground or buried underground, API 5L X46 pipes ensure secure and efficient fluid flow under varying conditions, making them essential for energy infrastructure, water management, and industrial pipeline systems in markets around the globe.
