Aman Pipes and Tubes stands out as a reliable manufacturer and supplier of top-notch Aluminium Instrumentation Tubing, based in Hyderabad, India. Renowned for their precision-engineered solutions, the company provides tubing products that fulfill the rigorous demands of process control and instrumentation systems. Their aluminium tubing is crafted using cutting-edge techniques to guarantee uniformity, dimensional accuracy, and resistance to corrosion. With a strong emphasis on quality, dependability, and prompt delivery, Aman caters to sectors like oil & gas, petrochemicals, pharmaceuticals, and power generation. Their customer-focused approach and dedication to excellence make them a go-to choice for aluminium instrumentation tubing solutions.
Aman Pipes and Tubes’ Aluminium Instrumentation Tubing is primarily crafted from high-performance aluminium alloys, including 6061 and 5052. These alloys are known for their outstanding corrosion resistance, impressive strength-to-weight ratio, and excellent weldability. The tubing generally boasts a tensile strength ranging from 150 to 300 MPa and a yield strength between 130 and 275 MPa, depending on the specific alloy and temper. It also offers good elongation (8–20%) and dimensional stability, ensuring reliable performance in precision settings. The lightweight design, paired with robust mechanical properties, makes it perfect for critical instrumentation and control applications.
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
ASTM B429 / ASME SB429 – Standard Specification for Aluminum-Alloy Extruded Structural Tube and Tube
EN AW-AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Round Tube
ISO AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Tubing
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| 5083 | 0.40 max | 0.40 max | 4.0 / 4.90 | 0.40 / 1.0 | 0.10 max | 0.25 max | 0.15 max | 0.05 / 0.25 | 0.05 max | Bal |
| 6061 | 0.7 | 0.4-0.8 | 0.8-1.2 | 0.15 | 0.15-0.4 | 0.25 | 0.15 | 0.15-0.35 | 0.005/0.15 | Remainder |
| 6068 | 0.50 max | 0.7 – 1.3 | 0.06-1.20 | 0.40-1.00 | 0.10 max | 0.20 max | 0.10 max | 0.25 max | 0.05 max | Bal |
| 7075 min | 2.10 | 1.20 | 5.10 | 0.18 | ||||||
| 7075 max | 0.50 | 0.40 | 2.90 | 0.30 | 2.00 | 6.10 | 0.20 | 0.28 | 0.05 |
| Alloy | Temper | UTS(Mpa) | % Elongation | Tensile Strength | Hardness Brinell | Proof Stress | Yield Strength (PSI) | Shear Strength (PSI) | Brinell Hardness | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||||||||
| 1100 | O | 75 | 110 | 20 | 25 | 29 | ||||||
| H12 | 95 | 130 | 5 | 6 | 7 | |||||||
| H14 | 110 | 145 | 3 | 4 | 5 | |||||||
| H16 | 130 | 165 | 2 | 3 | 4 | |||||||
| H18 | 150 | — | 2 | 2 | 3 | |||||||
| 5083 | 12 Min % | 275 – 350 MPa | 75 HB | 125 Min MPa | ||||||||
| 6061 | – | 45,000 | 12 | 40,000 | 31,000 | 95 | ||||||
| 6082 | 8 | 295 | 95 | – | 240 | – | – | |||||
| 7075 T6, T651 | 11 | 83-572 | 73- 503 | 150 | ||||||||
| 7075 T73, T7351 | 13 | 73-503 | 63-434 | NA | ||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Aluminium Instrumentation Tubing from Aman Pipes and Tubes ensures superior quality and performance. Aman Pipes and Tubes offer tubing manufactured with precision to meet the highest industry standards, providing excellent corrosion resistance, durability, and lightweight properties ideal for critical instrumentation applications. Their aluminium tubing is crafted to ensure seamless finish and enhanced reliability in demanding environments. Additionally, Brydon offers a wide range of custom sizes and prompt delivery, ensuring clients receive the best solutions tailored to their specific needs, backed by excellent customer service and technical expertise.
Aman Pipes and Tubes, one of the largest suppliers of Aluminium Instrumentation Tubing in Hyderabad, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Aluminium Instrumentation Tubing to meet your specific requirements. Our team at Aman Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@amanpipesandtubes.co.in.
| Grade | UNS | USA | Japan | France | ISO | WNR | EN | DIN | ISO | BS (OLD) |
| 1100 | A91100 | AA1100 | JIS A1100P | NF 1100 | Al 99.0 Cu. | – | – | – | – | – |
| 6082 | A96082 | AA6082 | – | – | – | 3.2315 | AW-6082 | AlMgSi1 | AlSi1MgMn | HE30 |
| 5083 | A95083 | 5083 | – | – | AlMg4,5Mn0,7 | 3.3547 | AW-AlMg4,5Mn0,7 | AlMg4,5Mn | – | – |
| 6061 | A96061 | AA6061 | – | – | – | 3.3211 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 |
| 7075 | A97075 | 7075 | 3.4365 | ENAW-AlZn5.5MgCu EN AW-7075 | AlZnMgCu1.5 | AlZn6MgCu | 7075 L95 L96, V95 |
Aman Pipes and Tubes’ Aluminium Instrumentation Tubing is extensively utilized in systems that require precise control of fluids or gases. It’s particularly suited for pressure, temperature, and flow measurement applications across industries such as oil & gas, petrochemical plants, power stations, and pharmaceutical manufacturing. This tubing finds its place in instrumentation panels, control lines, hydraulic systems, and pneumatic connections. Its corrosion resistance and lightweight characteristics also make it an excellent choice for marine and offshore environments. Designed for accuracy and reliability, it’s a vital component in various critical applications.
